trigLOC
LIGHT & ERGONOMIC

The remote lever for dropper seat posts
in shifter style

78€ onlineshop


trigLOC

The remote for dropper posts in shifter style.
Ergonomic, unrivalled light and strong.


OPTIMUM LEVER POSITION
ERGONOMICally ADJUSTABLE

With the two way axial and a five times rotational adjustment, the trigLOC remote lever meets all requirements for actuating a dropper post in the most ergonomic way.


CAREFUL
 BOWDEN CABLE CLAMP

With a well designed cable clamp, the bowden
cable is fixed without destroying.
With this feature you can reuse the bowden
cable for further installations.




COMPATIBLE WITH
SRAM TRIGGER MOUNT INTERFACE

By using the  SRAM Trigger Mount Interface (matchmaker) the trigLOC remote lever is compatible to almost all brake levers with the respective adapter. As an alternative to the direct mount, you can use our standard clamp for installing the trigLOC remote lever directly on the handle bar.


UNIVERSAL
USE

With the clever cable clamp you can use the lever for nearly all cable actuated dropper posts, no matter if lever side or post side cable clamping is needed.


UNIVERSAL INSTALLATION
WITH HANDLE BAR CLAMP

As an alternative to the SRAM trigger mount interface you can also install the trigLOC lever with the provided universal handle bar clamp.




AVAIBLE AS A BUNDLE
moveLOC 2 + trigLOC

The moveLOC 2 is available with the universal remote as well as with the trigLOC remote lever in shifter style as a bundle.



TECHNICAL DATA
trigLOC REMOTE LEVER



SCOPE OF SUPPLY

  • 1 x trigLOC remote lever with SRAM-Trigger-Mount-Interface
  • 1 x universal handlebar clamp with SRAM-Trigger-Mount-Interface and titanium bolt
  • 1 x reinforced cable return spring specific to retrofit on moveLOC dropper posts

INFOS & COMPATIBILITY

  • The trigLOC remote lever can be used at every bike with single drive train
  • The trigLOC remote lever is compatible for all brake levers with SRAM-Trigger-Mount interface (Matchmaker)
  • The trigLOC can also be used on all cable actuated dropper post






TECHNICAL DATA trigLOC

Weight [g]* 17
Adjustment range in handlebar direction [mm] 9
Adjustament range lever (rotary)  [°] +/- 8
Maximum activation angle  [°] 60
Maximum stroke bowden cable [mm] 12
Material bolts titanium
Material structural parts all alumnium parts are made from AL 7075 by 3D-milling process
Surface finsihing black anodised
Warranty 2 years, terms of guarantee

* Weight trigLOC with SRAM Trigger-Mount-Interface / without universal clamp



Form follows function

Design and function has not be contrary
